Description

Description

The strength and efficiency required to take on the most difficult tasks day after day. To do more tasks more quickly, put the gas pedal to the floor and accelerate to your top speed. robustness to keep you away from the shop and on the job. Unmatched quality that raises grass so steel blades can cut it, improving your lawn and providing you a cleaner cut.

Features

PRECISION DESIGNED ENGINE: The FX801V and other Kawasaki FX series engine options provide dependable power and performance.

Commercial grade transmission is made possible by the dependable and adaptable Hydro-Gear ZT-4400 transaxles.

DURABLE FRAME: Maximum durability is achieved with a structural tubed frame design that is heavy-duty.

BULLNOSE AIRFX DECK: The 52-inch, deep-profile bullnose AirFX deck has patent-pending Air-Gap baffles, which are made of sturdy steel spindloes.

COMFORT COMMAND CENTER: Its smooth, fast controls, almond-shaped grips, and luxurious suspension seat make it easy to use.

FUEL TANKS: Equipped with brand-new, 15-gallon dual fuel tanks.

PRODUCTIVITY IMPROVED: Ground speeds can reach 12 mph.

Full Spec

Model of Engine: Kaw FX801V
Positioning: 52.0 cu in (852 cc)
Fuel capacity: 15 gallons (56.7 liters)
Air Filter: Air Filter Canister

15 amp electrical charging system; 225 lbf (1000 N) clutch

DECK Mower Deck: Leading Edge, Adjustable, Front Lip Standard, AirFX Cutting System
52 inches (1320 mm) in width
Adaptable 6 Cutting Anti-Scalp Rollers Height: 25-139 mm (1.0-5.5 in)
18,586 fpm at 3500 engine rpm is the blade tip speed.
Release Flexible Molded Polymer Chute

Front and rear frames are made of welded 0.25-inch, 7-gauge steel, and the machine is 83.0 inches (2108 mm) long with 1.5 x 2.5-inch steel tubing.
Weight of the machine: 1371 wet pounds

HG ZT-4400 Hydrostatic Transaxles, Type of Transmission, Pump Displacement: 0.7 cu in (12 cc)
Each has a 1.1 gal (4.5 quart) oil capacity.
Speed Forward: 0–12.0 mph (0–19.3 km/h)
0.40 mph (0-6.4 km/h) is the reverse speed (mph).

Wheel dimensions: 24 x 10.5-12 for the drive wheel, 13 x 6.5-6 for the front caster wheel, and bolt-on for the castor arm attachment

The seat is a high-back, fully adjustable, mechanical suspension seat with fore-and-aft adjustment.
