Description

Description

To say that you require pro-grade power would be an understatement. Increase productivity and efficiency. Even at your fastest speeds, you can get maximum output torque while maintaining steady, smooth operation. Make sure you have enough fuel to go through your schedule. For an unparalleled, high-quality cut, a special bullnose design raises the grass before it reaches the mower blades.

Features

HIGH-PERFORMANCE ENGINE: The Briggs & Stratton Vanguard EFI or Kawasaki FX1000V engines provide significant commercial-grade strength.

A two-speed foot peadl on the rugged Hydro-Gear ZT-5400 hydrostatic transaxles allows for transport rates of up to 19 mph, making them ideal for commercial grade transmission.

HIGH-CAPACITY DUAL FUEL TANKS: Two 15-gallon fuel tanks are included.

BULLNOSE AIRFX DECK: The 61″ or 72″ bullnose AirFx deck with Air-Gap baffles provides excellent vacuum lift and effective airflow, and its sturdy, steel-fabricated spindles guarantee dependable operation.

COMFORT COMMAND CENTER: Its smooth, responsive controls, anti-vibration footplate, almond-shaped grips, and extremely tall suspension seat make it easy to use.

SWINGAWAY BUMPER AND HITCH ATTACHMENT: The rotating bumper with the added hitch system provides quick access to interior parts, increasing the effectiveness of tune-ups.

HIGH-SPEED MOWING: More productivity is possible with transport speeds of up to 19 mph and cutting rates of up to 13 mph.

15″ NO-FLAT CASTOR WHEELS: Dependable wheels increase cut and save downtime.

Full Spec

Model 61″

Model of Engine: Kaw FX1000V
Relocation: 60.9 cu in (999 cc)
Capacity for Fuel: 15.0 gal (56.7 Ltr)
Air Filter: Air Filter Canister

15 amp electrical charging system; 250 lbf clutch (1112N)

The DECK mower deck has an adjustable leading edge, an AirFX cutting system, and a front lip stand that is 61.0″ (1549mm) wide.
Adaptable The six anti-scalp rollers have a cutting height of 1.0-5.5″ (25-139mm).
18,800 fpm is the blade tip speed (3550 engine rpm).
Chute for Discharge: Flexible Molded Polymer

The front and rear frames are made of welded 0.25-inch, 7-gauge steel, and the machine is 87.0″ (2209mm) long with 1.5 x 2.5″ steel tubing.
Weight of the machine: 1500 wet pounds

HG ZT-5400 2-Speed Hydrostatic Transaxles with a 0.9″ cu (16cc) pump displacement are the type of transmission.
Each has a 1.4 gal (5.9qt) oil capacity. The forward speed ranges from 0 to 19.0 mph (0 to 30.5 km/h).
Speed in reverse (mph): 0-7.5 mph (0-12.0 km/h)

WHEELS: Front Castor Wheel Size: 15 x 6.5-6; Drive Wheel Size: 26 x 12.0-12 Bolt-On No-Flat Castor Arm Attachment

Description of the Seat: Full Mechanical Suspension Seat with Extra-High Back, Fore-Aft Adjustment, and Seat Slide Lever.

Model 72″

Model of Engine: Kaw FX1000V
Relocation: 60.9 cu in (999 cc)
Capacity for Fuel: 15.0 gal (56.7 Ltr)
Air Filter: Air Filter Canister

15 amp electrical charging system; 250 lbf clutch (1112N)

Deck Mower Deck: 72.0″ (1828mm) Wide, Front Lip Stand, Leading Edge, Adjustable, AirFX Cutting System
Adaptable Seven Anti-Scalp Rollers
Height of Cutting: 1.0-5.5″ (25-139mm)
18,152 fpm is the blade tip speed (3550 engine rpm).
Chute for Discharge: Flexible Molded Polymer

The front and rear frames are made of welded 0.25-inch, 7-gauge steel, and the machine is 87.0″ (2209mm) long with 1.5 x 2.5″ steel tubing.
Weight of the machine: 1541 wet pounds

HG ZT-5400 2-Speed Hydrostatic Transaxles with a 0.9″ cu (16cc) pump displacement are the type of transmission.
Each has a 1.4 gal (5.9qt) oil capacity. The forward speed range is 0–19.
